Product Description

Product NameHDPE Water Supply Pipe and Fitting
SpecificationDN20 - DN1400mm
PressurePN 0.6Mpa - PN 2.0Mpa
Raw MaterialPE80 PE100
Features· Environmental protection: Non-toxic any toxic additives.· Safety and Hygiene: widely apply in the drink water supply.· Excellent Durability: Over 50 years· Chemical  Corrosion resistance, impact resistance, high wear resistance.· The brittle Temperature:-60ºC· Cost Saving with high-efficiency: Lightweight. Simple connection, simple maintenance.
StandardsGB/T 19001-2016,GB/T 13663-2018,GB/T 24001-2016,EN 1220-1:2011 EN12201-2:2011+A1:2013,EN1555-1:2010,EN1555-2:2010,EN ISO 1452-1:2009,EN ISO 1452-22009,EN ISO 1452-3:2010
ApplicationUrban drink water supply   Agricultural irrigation.  Sewage discharge.              Landscape garden water supplyElectrical Cable threading.
ConnectionWelding
ColorBlack or Customized
DN (mm)Nominal Pressure
0.6Mpa0.8Mpa1.0Mpa1.25Mpa1.6Mpa2.0Mpa
Wall ThicknessWall ThicknessWall ThicknessWall ThicknessWall ThicknessWall Thickness
20



2.32.3
25



2.33
32

2.32.433.6
40
2.32.433.74.5
502.32.433.74.65.6
632.533.84.75.87.1
752.93.64.55.66.88.4
903.54.35.46.78.210.1
1104.25.36.68.11012.3
1254.867.49.211.414
1405.46.78.310.312.715.7
1606.27.19.511.814.617.9
1806.98.610.713.316.420.1
2007.79.611.914.718.222.4
2258.610.813.416.620.525.2
2509.611.914.818.422.727.9
28010.713.416.620.625.431.3
31512.11518.723.228.635.2
35513.616.921.126.132.239.7
40015.319.123.729.436.344.7
45017.221.526.733.140.950.3
50019.123.929.736.845.455.8
56021.426.733.241.250.862.5
63024.13037.446.357.270.3
71027.433.942.152.264.579.3
80030.638.147.458.872.689.3
90034.442.953.366.281.7
100038.247.759.372.590.2
120045.957.267.988.2

140053.566.782.4102.9

160061.276.294.1117.6

HDPE Pipe Application:
1.Urban area water-supply work system. Large diameter PE pipe is healthy and non-toxic and more suitable for urban water supply main conduit and buried tube.
2.Replace cement tube, iron pipe and steel tube. Applicable for renovation project and does not need large area excavation,   PE pipe can be widely used in old town of pipe network reconstruction.
3.Industrial materials transmission pipe. Chemical industry, chemical fiber, food, forestry, pharmacy, light industry and paper-making, metallurgical and other industrial raw material conveying pipe.
4.Landscaping water supply network. As landscaping project needs lots of water supply pipes, PE pipe is the best choice for its toughness and low costs.
5.Sewage discharge pipes. PE pipe have unique corrosion resistance, can be used in industrial waste water, sewage discharged pipe, low costs and maintenance costs .
6.Ore, mud transfers. PE pipe has high resistance to stress and wear resistance, can be widely applied in conveying ore, coal ash and river bait-casting mud.
